Vol. 08 · One wall

Decide one thing completely.

Idea and artifactArchive

§1 · Rule

Decide one surface completely. Keep the rest quiet.

Most rooms are decided by accumulation, a little of everything until nothing is decided. One surface, specified completely, gives the room its position.

Specs M-01 to M-06

Spec M-01Olive
Specimen M-01: plaster wall, olive
Sample area 720 × 960 px
Material
Plaster wall, as found
Colour, mean
#736c42
CIE L*a*b*
45 · -4 · +25
LRV, est.
15
Texture
T3 medium · σ 1.17
Light falloff
ΔL* 18
Specified for
A clinic waiting room. Lower the pulse before anyone is called.
Spec M-02Ochre
Specimen M-02: plaster wall, ochre
Sample area 720 × 960 px
Material
Plaster wall, as found
Colour, mean
#bb7a25
CIE L*a*b*
57 · +18 · +53
LRV, est.
26
Texture
T2 light · σ 0.75
Light falloff
ΔL* 30
Specified for
A reading room in winter.
Spec M-03Terracotta
Specimen M-03: plaster wall, terracotta
Sample area 720 × 960 px
Material
Plaster wall, as found
Colour, mean
#ad6840
CIE L*a*b*
51 · +24 · +34
LRV, est.
20
Texture
T1 fine · σ 0.66
Light falloff
ΔL* 23
Specified for
A family room in a hospital. Warm, not clinical.
Spec M-04Rose over rust
Specimen M-04: plaster wall, rose over rust
Sample area 720 × 960 px
Material
Plaster wall, as found
Colour, mean
#ad7264
CIE L*a*b*
54 · +22 · +17
LRV, est.
22
Texture
T2 light · σ 0.90
Light falloff
ΔL* 21
Specified for
A members’ room at eleven at night.
Spec M-05Distressed
Specimen M-05: plaster wall, distressed
Sample area 720 × 960 px
Material
Plaster wall, as found
Colour, mean
#917665
CIE L*a*b*
52 · +8 · +14
LRV, est.
20
Texture
T4 heavy · σ 2.31
Light falloff
ΔL* 31
Specified for
A new building that has to feel inherited.
Spec M-06Red
Specimen M-06: plaster wall, red
Sample area 720 × 960 px
Material
Plaster wall, as found
Colour, mean
#d56162
CIE L*a*b*
56 · +46 · +22
LRV, est.
24
Texture
T1 fine · σ 0.59
Light falloff
ΔL* 11
Specified for
A launch that needs one image people keep.

Method

Specimens are crops of site photographs in the archive. Colour is the mean of the sample area in sRGB, with CIE L*a*b* under D65. LRV is estimated from relative luminance; the photographs are uncalibrated, so treat it as a guide. Texture is the standard deviation of L* after light falloff is removed: T1 below 0.70, T2 to 1.00, T3 to 1.50, T4 above. Light falloff is the range of L* across the sample, a measure of the photograph, not the wall.
